Use with unit heaters and other shaft-mounted fan and blower equipment in dusty, dirty, noncombustible environments.
| Item | Unit Heater Motor |
| Motor Application | HVAC/R |
| Motor Sub Application | Unit Heater |
| Motor Design | Permanent Split Capacitor |
| HP | 1/4 |
| Nameplate RPM | 1140 |
| Voltage | 115/208-230 |
| Frame | 48Y |
| Motor Enclosure Design | Totally Enclosed Air-Over |
| Motor Mounting Type | Cradle Base |
| No. of Speeds | 1 |
| Hz | 60 |
| Phase | 1 |
| Full Load Amps | 3.1/1.6-1.6 |
| Motor Thermal Protection | Auto |
| Ins. Class | B |
| Motor Service Factor | 1 |
| Motor Bearings | Ball |
| Max. Ambient Temp. | 60 Degrees C |
| Motor Shaft Rotation | CW/CCW |
| Duty | Continuous |
| Overall Length | 12 3/8 in |
| Length Less Shaft | 7 1/4 in |
| Shaft Dia. | 1/2 in |
| Shaft Length | 4 9/16 in |
| Body Dia. | 5 5/8 in |
| Ring Dia. | 2 1/4 in |
| Ring to Ring Center | 6 7/8 in |
| Mounting Stud Pattern | 3-5/8 in x 3-5/8 in |
| Application | Dirty, Noncombustible Environments, Unit Heaters and Other Shaft-mounted Fan and Blower Equipment in Dusty |
| Standards | CSA Certified (LR43341/LR12645), UL Recognized (E46412/E49807) |
| Includes | 4MFD 370 V AC Capacitor |
| Voltage Compatibility | 115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240 |
